The RC15 series is a single AC current measuring relay, for AC signals, either directly or via a current transformer.
Adjustments for setpoint, hysteresis
Selectable activation or release of relay
1- or 2- pole relay output
Ikke alle vores produkter er i vores webshop, se datablad for andre modeller / Not all products are in the webshop Se data sheet for orther models
Fandt du ikke det søgte er I altid velkommen til at skrive til os
Sales@comadan.com
Single current monitoring relay for AC signal
Supply: 230 VAC
Range: 0.25A to 5A
1-pole 8A relay output
Single current monitoring relay for AC signals
Supply: 24VAC
Range: 0.05A to 1A
2-pole 5A relay output
Single current monitoring relay for AC signals
Supply: 24 VAC
Range: 0.25A to 5A
2-pole 5A relay output
Single current monitoring relay for AC signals
Supply: 230 VAC
Range: 0.05A to 1A
2-pole 5A relay output
Single current monitoring relay for AC signals
Supply 230 VAC
range: 0.25A to 5A
2-pole 5A relay output
Single current monitoring relay for AC signals
Supply: 12-60 VDC
Range: 0.25A to 5A
2-pole 5A relay output
